用CSS做出各种形状

作者:网页模板
类型:图文教程
点击次数:
发布时间:2019-06-22 12:02
分享到:
CSS能够制作各种形状。正方形和长方形这种简单的就不用说了,在网页布局中太常使用。加上一个宽度和高度,你就得到了你需要的准确大小的矩形。加上边界半径,你就可以把这个形状变圆,足够多的话,你可以把这些矩形变成圆和椭圆。

CSS还有强大的::before和::after伪类元素,这使我们有可能再添加两个形状到原始元素中。通过巧妙地定位、转换和许多其他技巧,我们可以在仅使用一个HTML元素的CSS中生成更加复杂的形状。

下面是一些总结,先从最简单的开始:

一、正方形
#square {
  width: 100px;
  height: 100px;
  background: red;
}


二、长方形
#rectangle {
  width: 200px;
  height: 100px;
  background: red;
}


三、圆形
#circle {
  width: 100px;
  height: 100px;
  background: red;
  border-radius: 50%
}


四、椭圆形
#oval {
  width: 200px;
  height: 100px;
  background: red;
  border-radius: 100px / 50px;
}


五、上三角
#triangle-up {
  width: 0;
  height: 0;
  border-left: 50px solid transparent;
  border-right: 50px solid transparent;
  border-bottom: 100px solid red;
}


六、下三角
#triangle-down {

  width: 0;

  height: 0;

  border-left: 50px solid transparent;

  border-right: 50px solid transparent;

  border-top: 100px solid red;

}


七、左三角
#triangle-left {

  width: 0;

  height: 0;

  border-top: 50px solid transparent;

  border-right: 100px solid red;

  border-bottom: 50px solid transparent;

}


八、右三角
#triangle-right {

  width: 0;

  height: 0;

  border-top: 50px solid transparent;

  border-left: 100px solid red;

  border-bottom: 50px solid transparent;

}


九、左上三角
#triangle-topleft {

  width: 0;

  height: 0;

  border-top: 100px solid red;

  border-right: 100px solid transparent;

}


十、右上三角
#triangle-topright {

  width: 0;

  height: 0;

  border-top: 100px solid red;

  border-left: 100px solid transparent;

}


十一、左下三角
#triangle-bottomleft {

  width: 0;

  height: 0;

  border-bottom: 100px solid red;

  border-right: 100px solid transparent;

}


十二、右下三角
#triangle-bottomright {

  width: 0;

  height: 0;

  border-bottom: 100px solid red;

  border-left: 100px solid transparent;

}


十三、分享箭头
#curvedarrow {

  position: relative;

  width: 0;

  height: 0;

  border-top: 9px solid transparent;

  border-right: 9px solid red;

  transform: rotate(10deg);

}

#curvedarrow:after {

  content: "";

  position: absolute;

  border: 0 solid transparent;

  border-top: 3px solid red;

  border-radius: 20px 0 0 0;

  top: -12px;

  left: -9px;

  width: 12px;

  height: 12px;

  transform: rotate(45deg);

}


十四、等腰梯形
#trapezoid {

  border-bottom: 100px solid red;

  border-left: 25px solid transparent;

  border-right: 25px solid transparent;

  height: 0;

  width: 100px;

}


十五、平行四边形
#parallelogram {

  width: 150px;

  height: 100px;

  transform: skew(20deg);

  background: red;

}


十六、六角星
#star-six {

  width: 0;

  height: 0;

  border-left: 50px solid transparent;

  border-right: 50px solid transparent;

  border-bottom: 100px solid red;

  position: relative;

}

#star-six:after {

  width: 0;

  height: 0;

  border-left: 50px solid transparent;

  border-right: 50px solid transparent;

  border-top: 100px solid red;

  position: absolute;

  content: "";

  top: 30px;

  left: -50px;

}


十七、五角星
#star-five {

  margin: 50px 0;

  position: relative;

  display: block;

  color: red;

  width: 0px;

  height: 0px;

  border-right: 100px solid transparent;

  border-bottom: 70px solid red;

  border-left: 100px solid transparent;

  transform: rotate(35deg);

}

#star-five:before {

  border-bottom: 80px solid red;

  border-left: 30px solid transparent;

  border-right: 30px solid transparent;

  position: absolute;

  height: 0;

  width: 0;

  top: -45px;

  left: -65px;

  display: block;

  content: '';

  transform: rotate(-35deg);

}

#star-five:after {

  position: absolute;

  display: block;

  color: red;

  top: 3px;

  left: -105px;

  width: 0px;

  height: 0px;

  border-right: 100px solid transparent;

  border-bottom: 70px solid red;

  border-left: 100px solid transparent;

  transform: rotate(-70deg);

  content: '';

}


十八、五边形
#pentagon {

  position: relative;

  width: 54px;

  box-sizing: content-box;

  border-width: 50px 18px 0;

  border-style: solid;

  border-color: red transparent;

}

#pentagon:before {

  content: "";

  position: absolute;

  height: 0;

  width: 0;

  top: -85px;

  left: -18px;

  border-width: 0 45px 35px;

  border-style: solid;

  border-color: transparent transparent red;

}


十九、六边形
#hexagon {

  width: 100px;

  height: 55px;

  background: red;

  position: relative;

}

#hexagon:before {

  content: "";

  position: absolute;

  top: -25px;

  left: 0;

  width: 0;

  height: 0;

  border-left: 50px solid transparent;

  border-right: 50px solid transparent;

  border-bottom: 25px solid red;

}

#hexagon:after {

  content: "";

  position: absolute;

  bottom: -25px;

  left: 0;

  width: 0;

  height: 0;

  border-left: 50px solid transparent;

  border-right: 50px solid transparent;

  border-top: 25px solid red;

}


二十、八边形
#octagon {

  width: 100px;

  height: 100px;

  background: red;

  position: relative;

}

#octagon:before {

  content: "";

  width: 100px;

  height: 0;

  position: absolute;

  top: 0;

  left: 0;

  border-bottom: 29px solid red;

  border-left: 29px solid #eee;

  border-right: 29px solid #eee;

}

#octagon:after {

  content: "";

  width: 100px;

  height: 0;

  position: absolute;

  bottom: 0;

  left: 0;

  border-top: 29px solid red;

  border-left: 29px solid #eee;

  border-right: 29px solid #eee;

}


二十一、爱心
#heart {

  position: relative;

  width: 100px;

  height: 90px;

}

#heart:before,

#heart:after {

  position: absolute;

  content: "";

  left: 50px;

  top: 0;

  width: 50px;

  height: 80px;

  background: red;

  border-radius: 50px 50px 0 0;

  transform: rotate(-45deg);

  transform-origin: 0 100%;

}

#heart:after {

  left: 0;

  transform: rotate(45deg);

  transform-origin: 100% 100%;

}


二十二、无穷大∞
#infinity {

  position: relative;

  width: 212px;

  height: 100px;

  box-sizing: content-box;

}

#infinity:before,

#infinity:after {

  content: "";

  box-sizing: content-box;

  position: absolute;

  top: 0;

  left: 0;

  width: 60px;

  height: 60px;

  border: 20px solid red;

  border-radius: 50px 50px 0 50px;

  transform: rotate(-45deg);

}

#infinity:after {

  left: auto;

  right: 0;

  border-radius: 50px 50px 50px 0;

  transform: rotate(45deg);

}


二十三、菱形
#diamond {

  width: 0;

  height: 0;

  border: 50px solid transparent;

  border-bottom-color: red;

  position: relative;

  top: -50px;

}

#diamond:after {

  content: '';

  position: absolute;

  left: -50px;

  top: 50px;

  width: 0;

  height: 0;

  border: 50px solid transparent;

  border-top-color: red;

}


二十四、钻石形状
#diamond-shield {

  width: 0;

  height: 0;

  border: 50px solid transparent;

  border-bottom: 20px solid red;

  position: relative;

  top: -50px;

}

#diamond-shield:after {

  content: '';

  position: absolute;

  left: -50px;

  top: 20px;

  width: 0;

  height: 0;

  border: 50px solid transparent;

  border-top: 70px solid red;

}


二十五、长菱形
#diamond-narrow {

  width: 0;

  height: 0;

  border: 50px solid transparent;

  border-bottom: 70px solid red;

  position: relative;

  top: -50px;

}

#diamond-narrow:after {

  content: '';

  position: absolute;

  left: -50px;

  top: 70px;

  width: 0;

  height: 0;

  border: 50px solid transparent;

  border-top: 70px solid red;

}


二十六、切割钻石形状
#cut-diamond {

  border-style: solid;

  border-color: transparent transparent red transparent;

  border-width: 0 25px 25px 25px;

  height: 0;

  width: 50px;

  box-sizing: content-box;

  position: relative;

  margin: 20px 0 50px 0;

}

#cut-diamond:after {

  content: "";

  position: absolute;

  top: 25px;

  left: -25px;

  width: 0;

  height: 0;

  border-style: solid;

  border-color: red transparent transparent transparent;

  border-width: 70px 50px 0 50px;

}


二十七、鸡蛋形状
#egg {

  display: block;

  width: 126px;

  height: 180px;

  background-color: red;

  border-radius: 50% 50% 50% 50% / 60% 60% 40% 40%;

}


二十八、吃豆人
#pacman {

  width: 0px;

  height: 0px;

  border-right: 60px solid transparent;

  border-top: 60px solid red;

  border-left: 60px solid red;

  border-bottom: 60px solid red;

  border-top-left-radius: 60px;

  border-top-right-radius: 60px;

  border-bottom-left-radius: 60px;

  border-bottom-right-radius: 60px;

}


二十九、聊天气泡
#talkbubble {

  width: 120px;

  height: 80px;

  background: red;

  position: relative;

  -moz-border-radius: 10px;

  -webkit-border-radius: 10px;

  border-radius: 10px;

}

#talkbubble:before {

  content: "";

  position: absolute;

  right: 100%;

  top: 26px;

  width: 0;

  height: 0;

  border-top: 13px solid transparent;

  border-right: 26px solid red;

  border-bottom: 13px solid transparent;

}


三十、十二角形
#burst-12 {

  background: red;

  width: 80px;

  height: 80px;

  position: relative;

  text-align: center;

}

#burst-12:before,

#burst-12:after {

  content: "";

  position: absolute;

  top: 0;

  left: 0;

  height: 80px;

  width: 80px;

  background: red;

}

#burst-12:before {

  transform: rotate(30deg);

}

#burst-12:after {

  transform: rotate(60deg);

}


三十一、八角形
#burst-8 {

  background: red;

  width: 80px;

  height: 80px;

  position: relative;

  text-align: center;

  transform: rotate(20deg);

}

#burst-8:before {

  content: "";

  position: absolute;

  top: 0;

  left: 0;

  height: 80px;

  width: 80px;

  background: red;

  transform: rotate(135deg);

}


三十二、八卦
#yin-yang {

  width: 96px;

  box-sizing: content-box;

  height: 48px;

  background: #eee;

  border-color: red;

  border-style: solid;

  border-width: 2px 2px 50px 2px;

  border-radius: 100%;

  position: relative;

}

#yin-yang:before {

  content: "";

  position: absolute;

  top: 50%;

  left: 0;

  background: #eee;

  border: 18px solid red;

  border-radius: 100%;

  width: 12px;

  height: 12px;

  box-sizing: content-box;

}

#yin-yang:after {

  content: "";

  position: absolute;

  top: 50%;

  left: 50%;

  background: red;

  border: 18px solid #eee;

  border-radius: 100%;

  width: 12px;

  height: 12px;

  box-sizing: content-box;

}


三十三、徽章
#badge-ribbon {

  position: relative;

  background: red;

  height: 100px;

  width: 100px;

  border-radius: 50px;

}

#badge-ribbon:before,

#badge-ribbon:after {

  content: '';

  position: absolute;

  border-bottom: 70px solid red;

  border-left: 40px solid transparent;

  border-right: 40px solid transparent;

  top: 70px;

  left: -10px;

  transform: rotate(-140deg);

}

#badge-ribbon:after {

  left: auto;

  right: -10px;

  transform: rotate(140deg);

}


三十四、太空入侵者
#space-invader {

  box-shadow: 0 0 0 1em red,

  0 1em 0 1em red,

  -2.5em 1.5em 0 .5em red,

  2.5em 1.5em 0 .5em red,

  -3em -3em 0 0 red,

  3em -3em 0 0 red,

  -2em -2em 0 0 red,

  2em -2em 0 0 red,

  -3em -1em 0 0 red,

  -2em -1em 0 0 red,

  2em -1em 0 0 red,

  3em -1em 0 0 red,

  -4em 0 0 0 red,

  -3em 0 0 0 red,

  3em 0 0 0 red,

  4em 0 0 0 red,

  -5em 1em 0 0 red,

  -4em 1em 0 0 red,

  4em 1em 0 0 red,

  5em 1em 0 0 red,

  -5em 2em 0 0 red,

  5em 2em 0 0 red,

  -5em 3em 0 0 red,

  -3em 3em 0 0 red,

  3em 3em 0 0 red,

  5em 3em 0 0 red,

  -2em 4em 0 0 red,

  -1em 4em 0 0 red,

  1em 4em 0 0 red,

  2em 4em 0 0 red;

  background: red;

  width: 1em;

  height: 1em;

  overflow: hidden;

  margin: 50px 0 70px 65px;

}


三十五、电视屏幕
#tv {

  position: relative;

  width: 200px;

  height: 150px;

  margin: 20px 0;

  background: red;

  border-radius: 50% / 10%;

  color: white;

  text-align: center;

  text-indent: .1em;

}

#tv:before {

  content: '';

  position: absolute;

  top: 10%;

  bottom: 10%;

  right: -5%;

  left: -5%;

  background: inherit;

  border-radius: 5% / 50%;

}


三十六、雪佛龙图标
#chevron {

  position: relative;

  text-align: center;

  padding: 12px;

  margin-bottom: 6px;

  height: 60px;

  width: 200px;

}

#chevron:before {

  content: '';

  position: absolute;

  top: 0;

  left: 0;

  height: 100%;

  width: 51%;

  background: red;

  transform: skew(0deg, 6deg);

}

#chevron:after {

  content: '';

  position: absolute;

  top: 0;

  right: 0;

  height: 100%;

  width: 50%;

  background: red;

  transform: skew(0deg, -6deg);

}


三十七、放大镜
#magnifying-glass {

  font-size: 10em;

  display: inline-block;

  width: 0.4em;

  box-sizing: content-box;

  height: 0.4em;

  border: 0.1em solid red;

  position: relative;

  border-radius: 0.35em;

}

#magnifying-glass:before {

  content: "";

  display: inline-block;

  position: absolute;

  right: -0.25em;

  bottom: -0.1em;

  border-width: 0;

  background: red;

  width: 0.35em;

  height: 0.08em;

  transform: rotate(45deg);

}


三十八、Facebook
#facebook-icon {

  background: red;

  text-indent: -999em;

  width: 100px;

  height: 110px;

  box-sizing: content-box;

  border-radius: 5px;

  position: relative;

  overflow: hidden;

  border: 15px solid red;

  border-bottom: 0;

}

#facebook-icon:before {

  content: "/20";

  position: absolute;

  background: red;

  width: 40px;

  height: 90px;

  bottom: -30px;

  right: -37px;

  border: 20px solid #eee;

  border-radius: 25px;

  box-sizing: content-box;

}

#facebook-icon:after {

  content: "/20";

  position: absolute;

  width: 55px;

  top: 50px;

  height: 20px;

  background: #eee;

  right: 5px;

  box-sizing: content-box;

}


三十九、月亮
 #moon {

  width: 80px;

  height: 80px;

  border-radius: 50%;

  box-shadow: 15px 15px 0 0 red;

}


四十、旗帜
#flag {

  width: 110px;

  height: 56px;

  box-sizing: content-box;

  padding-top: 15px;

  position: relative;

  background: red;

  color: white;

  font-size: 11px;

  letter-spacing: 0.2em;

  text-align: center;

  text-transform: uppercase;

}

#flag:after {

  content: "";

  position: absolute;

  left: 0;

  bottom: 0;

  width: 0;

  height: 0;

  border-bottom: 13px solid #eee;

  border-left: 55px solid transparent;

  border-right: 55px solid transparent;

}


四十一、扇形
#cone {

  width: 0;

  height: 0;

  border-left: 70px solid transparent;

  border-right: 70px solid transparent;

  border-top: 100px solid red;

  border-radius: 50%;

}


四十二、十字架
#cross {

  background: red;

  height: 100px;

  position: relative;

  width: 20px;

}

#cross:after {

  background: red;

  content: "";

  height: 20px;

  left: -40px;

  position: absolute;

  top: 40px;

  width: 100px;

}


四十三、房子
#base {

  background: red;

  display: inline-block;

  height: 55px;

  margin-left: 20px;

  margin-top: 55px;

  position: relative;

  width: 100px;

}

#base:before {

  border-bottom: 35px solid red;

  border-left: 50px solid transparent;

  border-right: 50px solid transparent;

  content: "";

  height: 0;

  left: 0;

  position: absolute;

  top: -35px;

  width: 0;

}


四十四、指路箭头
#pointer {

  width: 200px;

  height: 40px;

  position: relative;

  background: red;

}

#pointer:after {

  content: "";

  position: absolute;

  left: 0;

  bottom: 0;

  width: 0;

  height: 0;

  border-left: 20px solid white;

  border-top: 20px solid transparent;

  border-bottom: 20px solid transparent;

}

#pointer:before {

  content: "";

  position: absolute;

  right: -20px;

  bottom: 0;

  width: 0;

  height: 0;

  border-left: 20px solid red;

  border-top: 20px solid transparent;

  border-bottom: 20px solid transparent;

}


四十五、锁
#lock {

  font-size: 8px;

  position: relative;

  width: 18em;

  height: 13em;

  border-radius: 2em;

  top: 10em;

  box-sizing: border-box;

  border: 3.5em solid red;

  border-right-width: 7.5em;

  border-left-width: 7.5em;

  margin: 0 0 6rem 0;

}

#lock:before {

  content: "";

  box-sizing: border-box;

  position: absolute;

  border: 2.5em solid red;

  width: 14em;

  height: 12em;

  left: 50%;

  margin-left: -7em;

  top: -12em;

  border-top-left-radius: 7em;

  border-top-right-radius: 7em;

}

#lock:after {

  content: "";

  box-sizing: border-box;

  position: absolute;

  border: 1em solid red;

  width: 5em;

  height: 8em;

  border-radius: 2.5em;

  left: 50%;

  top: -1em;

  margin-left: -2.5em;

}

(责任编辑:网页模板)
  • 本文标签:
  • CSS 形状
CSS写个精美的手机登录页面
HTML+CSS做一个下拉菜单效果
